RJ45 Data/Network Curly Cords

PRO-CAT5E-PUa.jpgWe offer a special Industrial Grade Cat5e UTP Network cable

These do not use ordinary cat5e cable.
This special construction includes highly stranded wire:-
45 super fine strands of 0.08mm² 45/.08bc,

Also included is a Kevlar central strength members,



And our special polyurethane jacket.

These cords extend up to 4 times their compressed length.PRO-CAT5E-PUb.jpg
Series Part Number
PRO-Cat5e-PU-XXX (optional-T)
Where XXX is the coil length
Normally supplied unterminated.
Can be supplied with standard RJ45 connectors if required. Add -T suffix to the part number



Coil Lengths:



  • 300mm extends to 1.2m max
  • 500mm extends to 2m max
  • 1000mm extends to 4m max
  • 1800mm extends to 7.2m max
  • Custom (MOQ’s apply)


Please email sales@proconnect.com.au  for prices.

















We have a new cable which not only has a cat5e 4pr cable, but 2x 1.5mm² DC power cable as well, all in a very robust Polyurethan sheath.












We can also supply and fit special water resistant industrial grade RJ45 connectors!























We have an small quantity of a special  cable, which is two of the above cables formed into a figure 8 construction, Which we supply straight or curly.














Bulk regular straight patch cords available at wholesale prices.







6 thoughts on “RJ45 Data/Network Curly Cords

  1. Ross Dowse says:

    Hi all, would it be possible to make up 2 new cords for a mh-48 microphone. This mike belongs to a Yaesu FT 8900 dual bander.

    Cheers
    Ross

    • Paul Scott says:

      Hi Ross,
      Thanks for your comment.
      It would certainly be possible to make a couple up for you.
      But it looks like there are some really cheap ones available on eBay at present. (from Hong Kong etc)
      So think you might be better off getting a couple off eBay.?

      All the best…
      Paul.

  2. Colette Kuhn says:

    You do not possibly have a Distributor in South Africa that I could possibly contact?

    I urgently need CAT5 or CAT6 curly cord for a huge instalation.

    please let me know

    • Paul Scott says:

      Hi Colette,

      We don’t have a distributor there, but we would be happy to help you direct.
      Please email me with the details, and i’ll reply with a quote.



      Best regards

      Paul.
